PROJECTS CARRIED BY MR. ZOLFAGHARI


MR. ZOLFAGHARI HAD FEW CONTRATS OUT OF HIS FIRMS WITH OTHER CONSTRUCTION COMPANIES AS TECHNICAL SUPERVISOR, PROJECT MANAGER, SITE SUPER INTENDENT FROM 1979 TO 2013 . THESE PROJCTS ARE AS FOLLOWING

LIST OF PROJECTS

SOOFIAN CEMENT FACTORY - PHASE 2 DARAB-BANDAR ABBAS HIGHWAY SAVEH CONCRETE DAM
SAVEH DAM ACCESS ROAD GELEROOD CONCRETE DIVERSION DAM FOOMAN IRRIGATION CHANNEL
NOSOOD WATER TRANSFER PROJECT DUBAI INTERNATIONAL CITY ZAGROSS WATER TRANSFER PROJECT

SOOFIAN CEMENT FACTORY - PHASE 2

This project was a national project contracted by Lauzanne Company near Tabriz in Azaerbaijan. Mr. Zolfaghari job was to prepare list and position and locaton of all re-bars that was used in construction of siloes and was covered by conctrete with no certificate and approval from the Russians Resident Engineers. 3 thousand tons of re-bar were used and 300 tons were missing . Mr. Zolfaghari prepared statements and work orders and got approval from engineers for all lost re-bars. This was the first job of him after graduation.



MIANJANGAL-GAHKOM , SECTION 4

This project was a national project in Fars Providence , 70 Km from Darab to Bandar Abbas. The section was 30 Km obtaing 3 tunnels in total length of 2 Km and the highest bridge of Iran with the height of 70 meters from the base of the river, all in a horizontal curve between tunnel nuber 2 and 3 .


SAVEH DAM

This project was a national project in 25 km south west of Saveh in Central Providence. The client was Tehran Water and Sewage Authority and the consultant was Rom Electro from Romiania with inspectors from Russia. The dam had a height of 128 meters and was formed of double-curve concrete body. The main contractor was SABIR Co. and Mr.Zolfaghari was assigned to manage the project from top of foundation to completion but he quitted the job after 13 months for some personal problems and handed over the management to his vice. The foundation was done by late Mr. Engineer Siahpoosh. During Mr. Zolfaghari supervision in 1986 and 1987 the concreting of the first 60 meters height of dam was completed and all fortification and anchorage and injection were done. The biggest problem in concreting was the air temperature that in most of year raised to above 40 dgrees and raised the temperature of concrete to above 30 when the specs did not allow more than 18 degrees. In addition to warm weather, fresh cement that carried to the site by bonkers was about 70 degrees. Precooling and postcooling were the most important part of job. The precooling was done by 4 compressors and condunsors that produced cold water to wash aggregates, a cooling system to cool-off the fresh cement and also ice crushers that pour ice sheets to the concrete . The post cooling was carried out by using a network of pipes inside all blocks of concretes to flow the cold water at the time of pour and to keep temperature of concrete low during the curing period and let the shrinkage happened in a longer time to avoid any cracks in concrete. The Dam was completed in 1983 and impounded .


Description of pictures : From top to bottom and left to right : (1) The body of dam in elevation +40 (2) Fromwork installing for the evacution gate (3) Taking the boring and injection truck to the side galleries (4) THe installation and concrete pour for the main gates (5) A view of the dam at +48 (6) View of lake (7) View of dam


SAVEH DAM ACCESS ROAD

Saveh Dam on Garasu River is located at 16 Km off the main road from Saveh to Hamedan. To access the site of dam construction Sabir company was awarded a project to build this road. The road included a 40 meters wide bridge and more than 20 culverts. Concrete was supplied from dam site betching plant and transfered by mixers so most concreting occured during the night to keep concrete fresh and cold. This road completed in two years and now is serving as access to Saveh Dam and also part of Saveh-Tafresh road.


Description of pictures : From top to bottom and left to right : (1) Loading finisher for pavement (2) Four-span Bridge (3) Formworks on the bridge (4) Concreting


GELEH ROOD DIVERSION DAM ON SEPIDROOD RIVER, SANGAR, GILAN

This project was a joint project between Sepano Construction Company and WEM in Sangar near Rasht in Gilan Providence. WEM was in charge of project manage ment and executive of whole project. Sepano was in charge of finanance, and accounting. The project started in May 1983 and conpleted in April 1984. The job was to construct a 700-Meter wide diversion dam on Sepid Rood River to rais water to a an open channel to carry water for irrigation of more than 2000 acres of rice farms in Fooman. The client was Gilan Water and Eletricity Organization and the consultant and Resident Engineers were from client. The spillway and crown was built on a concrete mat that was supported by 160 concrete piles. The job was done in less tan a year and turned over to the client and now is operating. The passengesrs who pass the Imamzadeh Hashem can see the dam on their right hand side.


FOOMAN IRRIGATION CHANNEL

This project was to construct a diversion concrete dam on Sefidrood River in Sangar near Rasht, Capitol of Gilan and was rewarded to Sepano Construction Company by Gilan Province Water Authority d Sepano based on an agreement with Mr. Zolfaghari relegated the management and execution of project to Mr. Zolfaghari and Mr. Rahimi. The project started in May 1983 and comnpleted in April 1984. The job was to construct a 700-Meter wide diversion dam on Sepid Rood River to raise water to a an open channel to carry water for irrigation of more than 2000 acres of rice farms in Fooman. The spillway and crown was built on a concrete mat that was supported by 160 concrete piles. The job was done in less than a year and turned over to the client and now is operating. The passengers who pass the Imamzadeh Hashem can see the dam on their right hand side.


DUBAI INTERNATIONAL CITY INFRA-STRUCTURE

This project was rewarded in 2007 to a joint venture of General Mechanic Construction Company, Melli Sakhteman Construction Company and Tossar Construction Company. Mr. Zolfaghari was Melli Sakhteman representative in the Board of managers of the JV that was called GMT and his position in the project was Technical, Claim, and Contract Manager of the project. The Client was NAKHEEL from Dubai and its representative in project was BOVIS Co. from England. The purpose of project was to prepare lots with all utility in International City of Dubai for investors to purchase the lots and construct their buildings. The job obtained potable water and sewer pipe-line, Electricity and communication cabling, Rain run-off collection facilities, streets and sidewalks, lighting , curbs and pavement. The project was completed in four years and handed over to the client in 2012.


ZAGROSS DIVERSION DAM & TUNNEL

This project was a combination of a 4/5 Km and 9 Km tunnels and a diversion dam to transfer 70 Cubic Meters of Sirvan river to a dam in Gilan Gharb for agricultural usage. The client was Kermanshah Providence water & Electricity Authorities and the contractor was joint venture of Sepano Comstruction Company and Orsa construction company. Mr. Zolfaghari was project manager for 6 months to start main tunnel drilling by a Jambo Drill Machine and two drill wagons from both ends and the access tunnel, installation of batching plant and aggrigate production plant, and preparation of the dam site. The project started on spring of 2006 but is not completed yet.

Description of pictures : From top to bottom and left to right : (1) Tennel entrance from south end (2) Tunnel entrance from north end (3) Aggregate production and batching plants (4) Inside Tunnel with air blowing and electrical systems (5) Water accumulated in southern section of main tunnel (6) South tunnel dewatering , electricity and air blowing systems
